|Place of Origin:||China|
|Model Number:||SMSS 160L / B|
|Minimum Order Quantity:||1PC|
|Packaging Details:||Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice|
|Delivery Time:||5 - 30 Work Days|
|Payment Terms:||L/C, T/T, Western Union|
|Nominal Size:||160mm||Connection Size:||1 / 2|
|Ingress Protection.:||IP65 ( Weather Tight )||Connection:||Stainless Steel|
|Window:||Plain Instrement Glass Or Laminated Glass||Pointer:||Black Painted Aluminium|
6 Inch Manometer Liquid Filled Stainless Steel Pressure Gauge With SMSS 160mm Back And Bottom
Technical Specification Table
|Technical Specification||Nominal Size||63,100,150,200 and 250mm|
|Accuracy Class||Class 1.0|
|Ingress Protection.||IP65(Weather tight)|
|Connection Size||G1/4,G1/2 or NPT or others|
|Scale Range||Pressure 0..600 bar(SMSS Series), Vacuum -1 bar..0, Compound -1..24 bar|
|Filling||Dry or liquid filled|
|Tube Element Shape||P≤100 bar in c tube, P＞100 bar in helicoil|
|Operating Temperature||Ambient temperature -10° ..+70° C, Medium temperature 70° C Max.|
Additional error when pressure element tmperature
deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling
|Over Pressure Limit||130% of F.S.P≤100 bar, 115% of F.S.P＞100bar|
|Dial Graduation||Black graduation on white for single range, Black and red graduation on white for dual ranges|
SMSS Series is a premium design pressure gauge with fully stainless steel construction,liquid
fillable and with various option used in extreme corrosive & severe environment.SMSS Series
can be i ncorporate with most accessories such as Diaphragm chemical
seal,Siphon,dampener,etc.. to fur ther extend it usages.commonly,uses in Process
industries,Mining,Power plants,Steel mills,Pulp & Paper,Water & Sewage,Petrochemical
Accuracy class 1.0, Wide range application
All stainless steel construction, Knock-down system back and front flange
Bayonet lock case design, Over pressure up to 30% of Full Scale
Restrictor screw standard, Excellent vibration resist with liquid filling
Design scale ranges up to 600 bar
Casing and Bezel Ring : SS304
Sensing Element : SS316L
Connection : SS316L
Window : Plain instrement glass or laminated glass
Window gasket : Industrial rubber seal
Pointer : Black painted aluminium
Dial Plate : Aluminium alloy
Mounting Code :
L:Bottom entry, W:Bottom with back flange, B:Back entry
F:Back with front flange, Z:Back with bracket
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
