SMAPB6301 Series Digital Pressure Transmitter Ceramic Sensor Output 4 To 20mA

SMAPB6301 Series Digital Pressure Transmitter Ceramic Sensor Output 4 To 20mA

SMAPB6301 Series Digital Pressure Transmitter Ceramic Sensor Output 4 To 20mA

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMAPB6301

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Measuring Range: 0... 1bar To 0... 25bar Response Time: ≤10ms
Power Supply: 24VDC (or 12 To 36VDC) Output: 4 To 20mA
Process Connection: 1/2NPT Male Or 1/4NPT Male Or 1/8NPT Male Housing Material: Plastic

SMAPB6301 Series Digital Pressure Transmitter Ceramic Sensor Output 4 To 20mA







Technical Specification Table



SMAPB SERIES PRESSURE TRANSMITTER CERAMIC SENSOR :

SMAPB6301



Accuracy :

0 . 5 %F S , 1 % F S , 5 % F S ( including linearity . Hysteresis and repeatability



Measuring Range :

0... 1bar to 0... 25bar



Linear :

Superior to 0.5 % F S



Response time :

≤ 10ms



Power supply :

24VDC ( or 12 to 36VDC )



Output :

4 to 20mA



Load ( Ω ) :

< ( u - 12 ) / 0 . 02A



Proof pressure :

150 % F S



Burst pressure :

300 % F S



Operating Temp :

- 20 to + 85 ℃



Storing Temp :

- 40 to + 125 ℃



Process connection :

1 / 2NPT male or 1 / 4NPT male or 1 / 8NPT male



Wetted parts :

SS304



Housing material :

Plastic



Electrical Connections :

DIN43650 Plag Connector



Power Consume :

< 0 . 5W ( 24VDC )



Weight :

250g




Why choose us



1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .



FAQ



Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
