Easy Installation Submersible Level Transmitter For Hydrostatic Pressure Level Measurement

Easy Installation Submersible Level Transmitter For Hydrostatic Pressure Level Measurement

Easy Installation Submersible Level Transmitter For Hydrostatic Pressure Level Measurement

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMPB860

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Accuracy: 0 . 5 % F S Measuring Range: 0 ~ 5 M To 0 ~ 1500m
Power Supply: 12 To 36VDC Output: 4 ~ 20mADC
Load Resistance: 0 ~ 600 Ω Power Consume: < 5W ( 24VDC )

Easy Installation Submersible Level Transmitter For Hydrostatic Pressure Level Measurement







Technical Specification Table





Accuracy : 0 . 5 % F S



Measuring range : 0 ~ 5 m to 0 ~ 1500m



Linearity : Superior to 0 . 2 % F S



Temperature drift : < superior to ± 0 . 03 % F S / ℃



Stability : superior to 0 . 5 % F S for 1 year



Response time : 10ms



Power supply : 12 to 36VDC



Output : 4 ~ 20mADC



Load resistance : 0 ~ 600 Ω



Liquid Temp : - 10 ~ 60 ℃



Compensated temp : - 10 ~ 60 ℃



Storage temp : - 45 ~ 125 ℃



Installation position : Direct into the bottom of the liquid



Housing Material : 304 Stainless Steel or 316 Stainless Steel



Diaphragm material : 316L Stainless Steel



Breathing Cable Material : Polythene or PTFE



Weight :

Stainless Steel Pipe ( G1 ) : About 300g

Breathing cable ( G2 ) : About 65g / m

Junction box ( G3 ) : Above



Gross Weight ( G ) : G = G1 + G2 * Length ( m ) + G3



Power Consume : < 5W ( 24VDC )





Why choose us



1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .

3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .





FAQ



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
