NBSANMINSE Electro Pneumatic Solenoid Valve 0 . 15MPa - 0 . 8MPa Pressure

China NBSANMINSE Electro Pneumatic Solenoid Valve 0 . 15MPa - 0 . 8MPa Pressure supplier

Large Image :  NBSANMINSE Electro Pneumatic Solenoid Valve 0 . 15MPa - 0 . 8MPa Pressure

Product Details:

Place of Origin: NINGBO
Brand Name: NBSANMINSE
Certification: ISO9001
Model Number: 4A 300 -L - YPC Type

Payment & Shipping Terms:

Minimum Order Quantity: 20
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet or As Customer Advice
Delivery Time: Negotiation
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Medium: Air Action: External Polit
Pressure: 0 . 15 ~ 0 . 8MPa Temperature: - 5 ~ 60 ℃
Port Size: 1 / 4 " , 3 / 8 " Voltage: AC220V , DC24V , Etc
Thread: G / NPT / Etc Position: 5 / 2 , 5 / 3 , 3 / 2

NBSANMINSE Electro Pneumatic Solenoid Valve 0 . 15MPa - 0 . 8MPa Pressure







4A310-L-08 , 4A320-L-08 , 4A330C-L-08 , 4A330E-L-08 , 4A330P-L-08 , 4A310-L-10 ,

4A320-L-10 , 4A330C-L-10 , 4A330E-L-10 , 4A-330P-L-10 , 3A310-L-08 , 3A320-L-08 ,

3A310-L-10 , 3A320-L-10 .


4A Product Feature



1 . Structure in sliding column mode : good tightness and sensitive reaction .

2 . Three position air valves have three kinds of central function for your choice .

3 . Double air control valves have memory function .

4 . Internal hole adopts special processing technology which has little attrition friction , low start pressure and long service life .



3A Product Feature



1 . Structure in sliding column mode : good tightness and sensitive reaction .

2 . Double air control valves have memory function .

3 . Internal hole adopts special processing technology which has little attrition friction , low start pressure and long service life

4 . No need to add oil for lubrication .




Specification



Model : 4A310 - L - 08 , 4A330C - L - 08 , 4A330E - L - 08 , 4A310 - L - 10 , 4A330C - L - 10 ,

4A330E - L - 10 , 4A320 - L - 08 , 4A330P - L - 08 , 4A320 - L - 10 , 4A - 330P - L - 10



Position and Way No. : Two - position Five - way , Three - position Five - way



Effective Section Area : 25mm ² ( CV = 1 . 4 ) 18mm ² ( CV = 1 . 0 ) 30mm ² ( CV = 1 . 68 )



Model : 3A310 - L - 08 , 3A320 - L - 08 , 3A310 - L - 10 , 3A320 - L - 10



Position and Way No. : Two - position Three - way



Effective section area : 25mm ² ( CV = 1 . 4 ) 30mm ² ( CV = 1 . 68 )



Port Size : Air Inlet = Air Outlet = Exhaust = G1 / 4 ”



Working Medium : 40 Micron Filtered Air



Motion Pattern : External pneumatic actuation



Working Pressure : 0 .15 ~ 0 . 8MPa



Max . pressure Resistance : 1 . 2MPa



Voltage Range : - 5 ~ 60 ℃



Highest Action Frequency : 5 Cycle / Sec



Life : 20Million




Why choose us



1: Various style for each products and completely series pneumatic products .

2: High quality with competitive price .

3: Sample order & small quantity order is acceptable .

4: Provide free products information .

5: Reliable quality assured and active after-sell service




FAQ



Q: Could you offer the free samples ?

A: Yeah, we could offer the free samples for the massive products .



Q: What ' s your business scope ?

A: Our business scope is air cylinder , air source treatment , air solenoid valve , motorize valve , pneumatic valve , quick fitting , etc .



Q: what types of products you can make ?

A: We can make many kinds of stainless steel materials processing . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .



Q: Do you company have specialized technical personnel ?

A: Do you company have specialized technical personnel , they can design the product which the most meet your requirements .








NBSANMINSE Electro Pneumatic Solenoid Valve 0 . 15MPa - 0 . 8MPa PressureNBSANMINSE Electro Pneumatic Solenoid Valve 0 . 15MPa - 0 . 8MPa Pressure


Our products are high quality with 12 month guarantee ,and support paypal payment.
