FW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control Valves

FW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control Valves

FW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control Valves

Product Details:

Place of Origin: NINGBO
Brand Name: NBSANMINSE
Certification: ISO9001
Model Number: FW

Payment & Shipping Terms:

Minimum Order Quantity: 1 PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet or As Customer Advice
Delivery Time: Negotiation
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Medium: Mineral Oil ; Phosphate - Ester Pressure: 10 , 31 . 5 MPa
Temperature: - 20 ℃ ~ 70 ℃ Port Size: 08 / 10 / 12
Voltage: DC12V , DC24V,AC110V, AC220V Insulation Grade: IP 65

FW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control Valves







Technical specification



Specification 02 03

Working

Pressure ( MPa )

Oil Ports P. A . B 31 . 5 31 . 5
Oil ports T 10 10
Max . Flow ( L / min ) 80 120
Working fluid Mineral oil ; Phosphate - ester
Fluid Temp . ( ℃ ) - 20 ~ 70
Viscosity ( mm ² / s ) 2 . 8 ~ 100

Working

Voltage (V)

DC 12 24
AC 110V / 50Hz 220V / 50Hz
Max . Switch Frequency ( T / h) 15000 ( DC ) 7200 ( AC )
Insulation grade IP65
Weight ( kg ) Single solenoid 1 . 45 ( DC ) 1 . 4 ( AC ) 5 . 1 ( DC ) 4 . 3 ( AC )
Double Solenoids 1 . 95 ( DC ) 1 . 9 ( AC ) 6 . 7 ( DC ) 5 . 1 ( AC )
Cleanliness The maximum allowable cleanliness of the oil should be according to 9th degree of Standard Nas1638 . It is suggested that the minimum filter rating should be β 10 ≥ 75 .





Why choose us


1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .
3: High quality with competitive price .

4: Reliable quality assured and active after-sell service
5: One year quality guarantee



FAQ



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .



Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



Q: what types of products you can make ?
A: We can make many kinds of stainless steel materials and brass,aluminum . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .



Q: Do your company have specialized technical personnel ?
A: Design as your requirements,and have QC for make 100% inspection



FW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control ValvesFW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control ValvesFW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control ValvesFW Electric Hydraulic Solenoid Valve , Hydraulic Solenoid Directional Control Valves
