Aluminium Alloy Big Power Pneumatic Air Vibrator NTP Series Reciprocating Type

Minimum Order Quantity : 20 Price : Negotiation
Packaging Details : Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice Delivery Time : Negotiation
Payment Terms : L/C, T/T, Western Union Supply Ability : Negotiation
Place of Origin: China Brand Name: NBSANMINSE
Certification: ISO9001 Model Number: NTP

Detail Information

Type: Vibrator Material: Aluminium Alloy
Frequency: 43 ~ 146 Times Per Minute Max . Temperature: 150 ℃
Application: Hopper Feed , Casting Industry , Pipelinling , Etc Model: NTP23 , NTP32 , NTP48
High Light:

air powered vibrator

,

pneumatic vibration equipment

Product Description

Aluminium Alloy Big Power Pneumatic Air Vibrator NTP Series Reciprocating Type








Feature



Big power with lower noise .

Standard frequency is from 43 to 146 times per minute .

Excitation force is from 150 N to 2039 N .

The frequency and vibration amplitude can be adjusted via regulating the working pressure .

The normal maximum working pressure is 150 degrees centigrade .

( We can also make special type , such as 200 degrees centigrade ) .

The pneumatic hammer can be used for severe environment




Applications


The pneumatic piston vibrators series NTP are especially suitable for knocking off material adhering to container walls in funnels, containers, silos and hoppers. They can be used as drives for vibrating tables and chutes and as assitance for emptying containers.
Special features of NTP vibrators are: impacts like a rubber hammer or vibration with high peak acceleration.


Design and functioning principle


The vibration (linear) is produced by a freely vibrating differential pressure piston. In the standard version B+C the piston is knocking against an elastomer impact plate and works like a rubber hammer. In the version B without impact plate the piston works against an air cushion (noise reduced).
Hard knocking versions available.
The frequency can be adjusted by varying the pressure of the air supply and the amplitude by throttling the exhaust.
For operation a control valve is required (not included in scope of delivery).
Lubricationfree operation is possible in compliance with the recommendations of Netter.
ATEX compliant linear vibrators of the NTP series and units with stainless steel housing are available.




Why choose us


1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .

3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .

5: Reliable quality assured and active after-sell service
6: One year quality guarantee




FAQ



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .



Q: What ' s your delivery date ?
A: It depends on the number of orders . Delivery date is 7 - 30 days .if small order,pls buy from our aliexpress shop, If you need emergency products , we can speed up the production of the first arrangement .



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: what types of products you can make ?
A: We can make many kinds of stainless steel materials and brass,aluminum . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .



Q: Do your company have specialized technical personnel ?
A: Design as your requirements,and have QC for make 100% inspection




Aluminium Alloy Big Power Pneumatic Air Vibrator NTP Series Reciprocating Type 0
