Home ProductsCompressor Pressure Switch

Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55

Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55

    • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55
    • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55
    • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55
    • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55
    • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55
    • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55
  • Water , Air Compressor Pressure Switch With Standard Mounting Bracket PC55

    Product Details:

    Place of Origin: NINGBO
    Brand Name: NBSANMINSE
    Certification: CE
    Model Number: PC55

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 PC
    Price: Negotiation
    Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
    Delivery Time: Negotiation
    Payment Terms: L/C, T/T, Western Union
    Supply Ability: Negotiation
    Contact Now
    Detailed Product Description
    Voltage: AC110V AC220V , Etc Temperature: -20 ~ 110 ℃
    Full Load: 20A ,10A , 8A Locked Roter: 72A , 64A
    Type: Pressure Controller Switch Quality Standard: Best

    PC55 Pressure Switch For Refrigeration System , Water , Air And With Standard Mounting Bracket





    Electrical Function



    Rated Amps.(A)Rated Voltage (V)125VAC : 125VAC , 250VAC , 24VDC

    Full Load : 20A , 10A , 8A

    Locked Rotter : 72A , 72A , 64A

    Temperature : -20~110℃



    Model Range(bar) Differential(bar) Factory Setting(bar) Max Operating
    Min       Max Min        Max OFF       ON Pressure (bar)
    PC 5502 -0.5      2 0.2         0.7 1             0.5 16.5
    PC 5503 -0.5      3 0.35       1.5 2             1 16.5
    PC 5506 -0.5      6 0.6         4 3             2 16.5
    PC 5506M -0.5      6 Reset Differential ≤1bar 3 Manual Reset 16.5
    PC 5508 -0.2      7.5 0.7         4 3             2 20
    PC 5510 1          10 1            3 6             5 16.5
    PC 5514 2          14 1            4 10           8 20
    PC 5516 3          16 1            4 10           8 35
    PC 5520 5          20 2            5 16          13 35
    PC 5530 8          30 Fixed 3 to 5bar 20       15~17 35
    PC 5530M 8          30 Reset Differential ≤4bar 20 Manual Reset 35
    PC 5530D 5          30 3           10 20          15 35
    PC 5532 8          32 2            6 20          17 35
    PC 5542 8          42 4           10 30          25 46.5



    FAQ





    Q: Could you offer the free samples ?
    A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



    Q: what types of products you can make ?
    A: We can make many kinds of stainless steel materials and brass,aluminum . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .



    Q: Can the product be made with our logo and brand ?
    A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization for work.



    Why choose us


    1: Various style for each products and completely series pneumatic products .
    2: Large stock for fast shipping .
    3: Sample order & small quantity order is acceptable .
    4: One year quality guarantee
