RTD / TC Sensor Thermocouple Temperature Transmitter Smart Measuring Instrument

RTD / TC Sensor Thermocouple Temperature Transmitter Smart Measuring Instrument

RTD / TC Sensor Thermocouple Temperature Transmitter Smart Measuring Instrument

Product Details:

Place of Origin: China
Brand Name: Mkfale
Model Number: SMITT

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Power Consume: <0.5W(24VDC) Connection: Clamp , Flange , Screw
Senor: RTD / TC Diameter: Φ 4 , Φ 6 , Φ 8 , Φ 10 .
Local Indicator: LCD , LED Ambient Temp: - 25 … 85 ℃

RTD / TC Sensor Thermocouple Temperature Transmitter Smart Measuring Instrument







Technical Specification Table



Ambient Temp :

- 25 … 85 ℃



Storage Temp :

- 45 … 125 ℃



Humidity :

5 … 95 %



Accuracy of the indicator :

± 2 . 5 % ( 100 % scale )

± 1 . 0 % ( LED )

± 1 . 0 % ( LCD )



Power consume :

< 0 . 5 W ( 24VDC )



Local Indicator :

LCD , LED



Insert depth , the length and diameter size can be customized



Can be anti – corrosion features :

to protect pipe line four fluorine



With explosion – proof properties





Accuracy

± 0 . 2 % F S , ± 0 . 5 % F S

( Including linearity , hysteresis and repeatability )

Output ( 2 wires ) 4 … 20mA
Power supply 12 … 36 VDC ( Or 24VDC )
Process connection Clamp , flange , screw
Senor RTD / TC
RTD Pt100 , Pt1000 , Pt 500
Tc K , E , S , J , T , Etc
Range Optional
Material 304 , 316 Stainless Steel , Corundum Tube , Etc
Diameter Φ 4 , Φ 6 , Φ 8 , Φ 10



Why choose us


1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .



FAQ



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.


Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
