Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure

Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure

  • Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure
  • Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure
Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure
Product Details:
Place of Origin: NINGBO
Brand Name: NBSANMINSE
Certification: ISO9001
Model Number: 4N200 - M YPC Type
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet or As Customer Advice
Delivery Time: Negotiation
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Medium: Air Action: Internal Pilot
Pressure: 0. 15 ~ 0. 8MPa Temperature: - 5 ~ 60 ℃
Port Size: 1 / 8 " , 1 / 4 " Thread: G / NPT
Position: 2 / 5 , 3 / 5 Voltage: DC12V , DC24V , AC24V , AC220V , Etc
High Light:

pneumatic air valve

,

pneumatic directional control valve

Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure





4N210 – 06M , 4N230C – 06M , 4N230E – 06M ,  4N210 – 08M , 4N230C – 08M , 4M230E – 08M ,

4N220 – 06M ,  4N230P – 06M ,  4N220 – 08M ,  4N230P – 08M




Specification



Model : 4N210 – 06M , 4N230C – 06M , 4N230E – 06M , 4N210 – 08M , 4N230C – 08M ,

4N230E – 08M , 4N220 – 06M , 4N230P – 06M , 4N220 – 08M , 4N230P – 08M



Position and Way No. : Two - Position Five - Way Three - Position Five - Way



Effective section area : 14mm ² ( CV = 0 . 78 ) 16mm ² ( CV = 0 . 89 ) 12mm ² ( CV = 0 . 67 )



Port Size : Air Inlet = Exhaust = G1 /  8 ”  Air Inlet = G1 /  4 ” Exhaust = G1 /  8 ”



Working Medium : 40 Micron Filtered Air



Motion Pattern : Inner Guide Type



Working Pressure : 0 . 15 ~ 0 . 8MPa



Max . pressure Resistance : 1 . 2MPa



Temperature : - 5 ~ 60 ℃



Power Consumption : - 15 % ~ + 10 %



Power Consumption : AC : 3 . 5VA , DC : 3W



Insulation & Protection Class : F Class . IP65



Wiring Form : Lead Wire Or Connector Type



Highest Action Frequency : 5 Cycle / Sec



Shortest Excitation Time : 0 . 05 Second



Life : 20 Million




Why choose us



1: High quality with competitive price .
2: Sample order & small quantity order is acceptable .

3: Provide free products information .
4: Reliable quality assured and active after-sell service
5: One year quality guarantee




FAQ



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .



Q: What ' s your delivery date ?
A: It depends on the number of orders . Delivery date is 7 - 30 days . If you need emergency products , we can speed up the production of the first arrangement .



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any color .



Q: Do you company have specialized technical personnel ?
A: Do you company have specialized technical personnel , they can design the product which the most meet your requirements .



Q: Can the product be made with our logo and brand ?
A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization if it is possible .






Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure 0Professional Namur Mount Solenoid Valve Pneumatic 0. 15MPa - 0. 8MPa Pressure 1




Our products are high quality with 12 month guarantee ,and support paypal payment.
