SMFDF Water Solenoid Valve Normally Closed Miniature Flow Control Valve

SMFDF Water Solenoid Valve Normally Closed Miniature Flow Control Valve

  • SMFDF Water Solenoid Valve Normally Closed Miniature Flow Control Valve
  • SMFDF Water Solenoid Valve Normally Closed Miniature Flow Control Valve
SMFDF Water Solenoid Valve Normally Closed Miniature Flow Control Valve
Product Details:
Place of Origin: China
Brand Name: Mkfale
Model Number: SMFDF
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation
Contact Now
Detailed Product Description
Rated Voltage: AC110V , AC220V , DC12V , DC24V Frequency: 50 / 60Hz
Max , Pressure: 3.0MPa , 4.2MPa Refrigerant: R12 , R22 , R502 , R134a , R407c , R410a Etc
Service Life: > 100 , 000 Times Coil Temp Rise: ≤ 80K
High Light:

magnetic solenoid valve

,

electronic solenoid valve

SMFDF Water Solenoid Valve Normally Closed , Miniature Flow Control Valve







Porduct Introduction



SMFDF type is a kind of mini-flow solenoid valve, which is mainly used for adjusting the defrost and controlling the refrigerant flow direction of the refrigeration system. At present it is widely used in air-conditioner,dehumidity unit and ice maker etc.



Technical Parameters



Rated Voltage: AC110V AC220V DC12V DC24V
Frequency: 50/60Hz
Max.operating pressure: 3.0 Mpa 4.2Mpa
Suitable Refrigerant: R12, R22, R502, R134a, R407c, R410a etc
Fluid permission temperature: -30℃ ~ +120℃
Ambient Temperature:-
lnternal leakage: SMFDF2A=300ml/min, SMFDF6A=500ml/min (with 2.1 Mpa air)
Service Life: >100,000 times
Coil temperature rise: ≤ 80K



Model Port Size Connection Size ( mm ) Opening pressure Differential ( Mpa ) Max . Working Pressure ( Mpa ) Operating Principles
SMFDF - 2A Φ2 6.5 0 2.5 3 Normal Close
SMFDF - 3A Φ3 6.5 0 2.5 3 Normal Close
SMFDF - 4A Φ4 6.5 0 2.5 3 Normal Close
SMFDF - 6A Φ5 . 8 8 0 2.5 3 Normal Close
SMFDF - 8A Φ8 9.52 0 2.5 3 Normal Close




Why choose us


1: Various style for each products and completely series industry instruments.

2: Provide free products information .
3: Reliable quality assured and active after-sell service
4: Large stock for fast shipping .
5: High quality with competitive price .



FAQ



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.


Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
