MIS / MIW Escapements Servo Electric Grippers Low Pressure ISO9001 Certification
Specifications
Series : MIW ( Double Finger ) , MIS ( Single Finger )
Fluid : Air
Operating Pressure : 0 . 2 to 0 . 7 MPa
Ambient Temperature and fluid temperature : - 10 to 60 ℃ ( No freezing )
Lubrication : Non
Action : Double acting
Auto switch ( optional ) Note ) : Solid state auto switch ( 3 – wire , 2 – wire )
Stroke Tolerance : +1mm
0mm
Theoretical Output
| Bore Size ( mm ) |
Rod Size ( mm ) |
Operating direction |
Piston area ( mm ² ) |
Operating Pressure MPa |
| 0 . 2 |
0 . 3 |
0 . 4 |
0 . 5 |
0 . 6 |
0 . 7 |
| 8 |
4 |
OUT |
50 |
10 |
15 |
20 |
26 |
31 |
36 |
| IN |
38 |
7 |
11 |
15 |
19 |
23 |
26 |
| 12 |
6 |
OUT |
113 |
23 |
34 |
45 |
57 |
68 |
79 |
| IN |
85 |
17 |
26 |
34 |
43 |
51 |
60 |
| 20 |
10 |
OUT |
314 |
63 |
94 |
126 |
157 |
188 |
220 |
| IN |
236 |
47 |
71 |
94 |
118 |
142 |
165 |
| 25 |
10 |
OUT |
491 |
98 |
147 |
196 |
245 |
295 |
344 |
| IN |
412 |
82 |
124 |
165 |
206 |
247 |
288 |
| 32 |
12 |
OUT |
804 |
161 |
241 |
322 |
402 |
482 |
563 |
| IN |
691 |
138 |
207 |
276 |
346 |
415 |
484 |
