2W Series Solenoid Valve Brass Valve Water Valve Steam Valve Anti - Explosion Solenoid Valve
Contact Person : Ina Chen
Phone Number : 0086-15168536055
WhatsApp : +8615168536055
| Minimum Order Quantity : | 20 | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice | Delivery Time : | 5 - 30 Work Days |
| Payment Terms : | L/C, T/T, Western Union | Supply Ability : | Negotiation |
| Place of Origin: | China | Brand Name: | Mkfale |
|---|---|---|---|
| Model Number: | SM |
|
Detail Information |
|||
| Refrigerant: | R12 , R22 , R134a , R404 , R407C , R410 , R502 | Media Temp: | - 30 ℃ ~ + 105 ℃ |
|---|---|---|---|
| Service: | 100 , 000 Cyeles | Pressure: | 3 . 0 MPa |
| Principles: | Direct Acting , Diaphragm Pliot Operated | Port Size (mm): | 2.5 , 7.0 , 12.5 , 16.5 , 25.5 |
| Highlight: | electronic solenoid valve,electric solenoid valve |
||
Product Description
High Performance Water Solenoid Valve For Refrigeration Compressor Group Etc
Porduct Introduction
This Solenoid Valve is an automatic control parts used in liquid line,suction line and steam line of refrigeration system to control the refrigerant to pass or not pass , the valve is widely used in refrigeration compressor group , central air-conditioning , coldstorage equipment and bus air - conditioning system ..
Technical Parameters
| Refrigerant | R12 , R22 , R134a , R404 , R407C , R410 , R502 |
| Media Temperature | 30 ℃ ~ + 105 ℃ |
| Service | 100,000 cyeles |
| Working Pressure | 3 . 0 MPa |
| Model | Operating Principles |
Port Size (mm) |
Connection Size | Opening Pressure Differential(bar) |
KV factor (m3/h) |
|||
| SAE(in) | ODF | Min | MOPD | |||||
| in. | mm | |||||||
| SM-1020/2 | Direct Acting |
2.5 | 1/4" | 0 | 21 | 0.175 | ||
| SM-1020/3 | 3/8" | 0.23 | ||||||
| SM-1028/2 | - | 1/4" | 0.15 | |||||
| SM-1028/3 | - | 3/8" | 0.23 | |||||
| SM-1064/3 | Diaphragm Pliot Operated |
7 | 3/8" | - | 0.05 | 0.8 | ||
| SM-1064/4 | 1/2" | - | ||||||
| SM-1068/3 | - | 3/8" | ||||||
| SM-1068/4 | - | 1/2" | ||||||
| SM-1070/4 | 12.5 | 1/2" | - | 2.2 | ||||
| SM-1070/5 | 5/8" | 2.61 | ||||||
| SM-1078/4 | 1/2" | 2.2 | ||||||
| SM-1078/5 | 5/8" | 16 | 2.61 | |||||
| SM-1078/6 | 3/4" | |||||||
| SM-1079/7 | 7/8" | 22 | ||||||
| SM-1098/6 | 16.5 | 3/4" | 4.8 | |||||
| SM-1098/7 | 7/8" | 22 | 5.7 | |||||
| SM-1099/9 | 1-1/8" | |||||||
| SM-1078/9 | 25.5 | 1-1/8" | 10 | |||||
| SM-1079/11 | 1-3/8" | 35 | ||||||
Why choose us
1: Sample order & small quantity order is acceptable .
2: Customize according to your special request .
3: Provide free products information .
4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee
FAQ
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
