FL-105-300 FL-105-350 FL-105-440 FL-105-600 FL-105-670 FL-105-A Perfect Steel Flat Plate Level Gauge For Oil

Large Image : FL-105-300 FL-105-350 FL-105-440 FL-105-600 FL-105-670 FL-105-A Perfect Steel Flat Plate Level Gauge For Oil

Product Details:

Place of Origin:	CHINA
Brand Name:	NBSANMINSE
Certification:	ISO9001
Model Number:	FL-105-300 FL-105-350 FL-105-440 FL-105-600 FL-105-670 FL-105-A

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiate
Packaging Details:	Box
Delivery Time:	5-30days
Payment Terms:	T/T,L/C
Supply Ability:	10000PCS

Contact Now

FL-105-300 FL-105-350 FL-105-440 FL-105-600 FL-105-670 FL-105-A Perfect Steel Flat Plate Level Gauge For Oil

Description

Code:	FL-105-300 FL-105-350 FL-105-440 FL-105-600 FL-105-670 FL-105-A	Size（mm）:	L 300 350 440 600 670 A L1 145 172 200 350 420 B D 115(105) D1 85(75) D2 65(55)
Part Name:	Valve Body Sealing Glass Gasket Glass	Material:	Q235,forged Steel Bushing Graphite Low Alkali High Borosilicate
Nominal Pressure:	2.5（4.0）Mpa	Strength Test Pressure:	4.0（6.4）Mpa
Seal Test Pressure:	2.5（4.0）Mpa	Operation Tempe:	≤225℃
Working Medium:	Water, Steam, Oil
Highlight:	FL-105-300 Flat Plate Level Gauge , FL-105-350 Flat Plate Level Gauge , Oil Flat Plate Level Gauge

Hot spot of 105 steel flat plate level gauge: Advantages of flat plate level gauge: professional manufacturer | suitable for high temperature | good quality. Flat level gauges are suitable for various complex measurements, such as small dielectric constant media, large temperature and pressure changes, corrosive working conditions, media such as fly ash, and volatile corrosive liquid media Order now!

FL-105-300 FL-105-350 FL-105-440 FL-105-600 FL-105-670 FL-105-A Perfect Steel Flat Plate Level Gauge For Oil 0

code	size(mm)					Part name	material
	L	L1	D	D1	D2
FL-105-300	300	145	115(105)	85(75)	65(55)
FL-105-350	350	172
FL-105-440	440	200				valve body	Q235, forged steel
FL-105-600	600	350				Sealing	bushing
FL-105-670	670	420				Glass gasket	graphite
FL-105-A	A	B				glass	Low alkali high borosilicate
Nominal pressure		2.5(4.0)Mpa
strength test pressure		4.0(6.4)Mpa
Seal test pressure		2.5(4.0)Mpa
operation temperature		≤225℃
Working medium		Water, steam, oil
