| VQ |
2 |
1 |
A |
1 |
1 |
|
Series/Orifice diameter |
Valve type |
|
|
Coil voltage |
| 2:VQ20 |
|
A:Single unit |
1 |
AC100V50/60Hz |
| 3:VQ30 |
M:For manifold |
2 |
AC200V50/60Hz |
|
|
3 |
AC110V50/60Hz |
| 5 |
DC24V |
| 6 |
DC12V |
| 9 |
Other |
| G |
□ |
C6 |
| Electrical entry |
Electricity circuit |
Port size |
| G:Grommet |
symbol |
DCvoltage |
ACvoltage |
C6 |
One-touch fiting forΦ6 |
| Y:DIN terminal |
Nil |
With power-saving circuit
(With surge voltage suppressor protection circuit)
|
with full wave rectifier circuit
(With surge voltage suppressor protection circuit)
|
C8 |
One-touch fiting forΦ8 |
| YO:DIN terminal without connect |
Z |
With power-saving circuit
(With light/surge voltage suppressor protection circuit)
|
with full wave rectifier circuit
(With light/surge voltage suppressor protection circuit)
|
C10 |
One-touch fiting forΦ10 |
|
H |
High speed response type
(Without energy-saving, light/surge
voltage suppressor circuit) |
|
C12 |
One-touch fiting forΦ12 |
| British Designation |
Domestic Designation |
Nominal Diameter |
External Thread - Outer Diameter (mm) |
Internal Thread - Inner Diameter (mm) |
| G1/8 |
1 Fen |
DN6 |
9.5±0.2 |
8.8±0.2 |
| G1/4 |
2 Fen |
DN8 |
12.5±0.3 |
11.5±0.3 |
| G3/8 |
3 Fen |
DN10 |
16.2±0.3 |
15.3±0.3 |
| G1/2 |
4 Fen |
DN15 |
20.3±0.3 |
19.5±0.3 |
| G3/4 |
6 Fen |
DN20 |
25.7±0.5 |
24±0.5 |
| G1 |
1 Cun |
DN25 |
32.5±0.5 |
30.5±0.5 |
| G1-1/4 |
1.2 Cun |
DN32 |
41.3±0.5 |
39.5±0.5 |
| G1-1/2 |
1.5 Cun |
DN40 |
47.8±0.5 |
46.6±0.5 |
| G2 |
2 Cun |
DN50 |
59.6±0.5 |
| Standard Specifications |
|
VQ20 |
VQ30 |
| multirow{10}{*}{Valve Specifications} |
Series |
VQ20 |
VQ30 |
|
Valve Structure |
multicolumn{2}{c}{Pilot-operated 2-way valve} |
|
|
Fluid Used |
multicolumn{2}{c}{Air, Inert Gas (Note 1)} |
|
|
Ambient Temperature and Fluid Temperature in Use |
multicolumn{2}{c}{-10~50℃ (Note 2)} |
|
|
Lubrication |
multicolumn{2}{c}{Not Required} |
|
|
Manual Operation |
multicolumn{2}{c}{Locking Type (Tool Required) (Note 3)} |
|
|
Shock Resistance, Vibration Resistance |
multicolumn{2}{c}{150 / 30m/s² (Note 4)} |
|
|
Protection Structure |
multicolumn{2}{c}{Dust-proof (Note 5)} |
|
|
Internal Leakage (cm³/min) |
multicolumn{2}{c}{15 or less} |
|
|
External Leakage (cm³/min) |
multicolumn{2}{c}{15 or less} |
|
|
Mounting Method |
multicolumn{2}{c}{Free} |
|
|
Mass |
46g |
80g |
| multirow{6}{*}{Electrical Specifications} |
Rated Coil Voltage |
multicolumn{2}{c}{DC12V, DC24V, AC100V, AC110V, AC200V} |
|
|
Allowable Voltage Fluctuation |
multicolumn{2}{c}{±10% of Rated Voltage} |
|
|
Coil Insulation Class |
multicolumn{2}{c}{Equivalent to Class B} |
|
|
multirow{3}{*}{Power Consumption} |
DC (with Power-saving Circuit) |
multicolumn{2}{c}{Starting: 2.9W, Holding: 0.6W} |
|
|
DC (without Power-saving Circuit) |
multicolumn{2}{c}{2.9W} |
|
|
AC |
multicolumn{2}{c}{2VA} |
|
Lead Wire Exit Method |
multicolumn{2}{c}{Direct Lead-out Type, DIN Socket Type} |
|
| Characteristic Specifications |
|
|
VQ20 |
|
VQ30 |
|
| multirow{4}{*}{Flow Characteristics} |
Series |
|
multicolumn{2}{c}{VQ20} |
multicolumn{2}{c}{VQ30} |
|
|
|
Port Size |
φ6 |
φ8 |
|
φ10 |
φ12 |
|
C [(text{dm}^3/(text{s·bar}))] |
1.4 |
1.5 |
|
2.8 |
3.0 |
|
b |
0.23 |
0.42 |
|
0.42 |
0.37 |
|
(C_v) |
0.33 |
0.39 |
|
0.80 |
0.81 |
| multicolumn{3}{l}{Minimum Operating Pressure Difference} |
multicolumn{4}{c}{0.01MPa (Note 3)} |
|
|
|
|
|
| multicolumn{3}{l}{Maximum Operating Pressure Difference} |
multicolumn{2}{c}{0.6MPa} |
multicolumn{2}{c}{0.5MPa} |
|
|
|
|
| multirow{3}{*}{Response Time (Note 1)} |
Electrical Circuit |
|
With Power-saving Circuit |
High-speed Response Type (Note 2) |
With Power-saving Circuit |
High-speed Response Type (Note 2) |
|
ON |
|
10ms or less |
7ms or less |
25ms or less |
20ms or less |
|
OFF |
|
15ms or less |
5ms or less |
15ms or less |
5ms or less |
Q: Could you offer the free samples ?
A: Yeah, but it depends products, Pls contact us ina@pneuhydr.com or whatsapp 0086 15168536055
Q: What ' s your business scope ?
A: Our business scope is service of exporter automation parts with full container, and sell air cylinder , air source treatment , solenoid valve , air valve, motorize valve , Brass valve, hydraulic valve, hydraulic cylinder, air and oil fitting, pressure gauge etc .
Q: What types of products you can make ?
A: We can make many kinds of stainless steel, brass ,aluminum materials processing .like high pressure Valve / solenoid valve / electric valve / water valve/pneumatic valve/air cylinder/hydraulic valve/hydraulic accumulator products and so on .
Q: Can the product be made with our logo and brand ?
A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization if it is possible .
Q:Can you provide original famous pneumatic and hydraulic,instruments brand goods ?
A: Yes,We can supply like Festo,Smc,Ckd,Burket,Hydac,Rexroth,Siemens,Rosemount,Marsh ,Endress+Hauser etc.
Q: Is there a warranty available?
A: Yes, normally products is one year quality guarantee.
Q: Is the connector in British or Metric system? What is the difference between PT, NPT, and G threads?
A: The G thread is cylindrical and does not seal itself, requiring additional gaskets to prevent leakage. PT and NPT are conical, and the internal and external threads become tighter and tighter when tightened. Sealing is achieved through the deformation of the threads, and sealant or tape is usually used in conjunction to enhance the sealing effect
G-thread is a cylindrical straight pipe used for non sealed connections; PT thread is a conical tube that relies on the deformation and sealing of the thread itself; NPT is also a conical tube with a tooth profile angle of 60 degrees, mainly used in North America
Q: How to convert pressure units: MPa, bar, psi, kg/cm ²?
A: 1MPa=10bar≈145psi≈10kg
Q:What usually causes the burnout of solenoid valve coils?
A:Incorrect voltage and hz, frequent switching, pilot head entering liquid,valve core and spring problem,environment hot,heavy vibration etc.
Q: What should be noted for pneumatic components in high temperature or extremely cold environments?
| Focus Point |
High Temperature Environment Countermeasures |
Extreme Cold Environment Countermeasures |
| Seals |
Fluororubber, PTFE |
Low-temperature nitrile, silicone rubber, polyurethane |
| Lubrication |
High-temperature synthetic grease (low volatility) |
Low-temperature grease (low pour point, low viscosity) |
| Air Supply Treatment |
Strengthen cooling, efficient water removal |
Ultra-low dew point drying (refrigeration + adsorption type), heat tracing |
| Metal Components |
Reserve expansion clearance |
Select materials with low-temperature toughness, prevent leakage due to cold shrinkage |
| Control Components |
High heat-resistant grade coils, heat dissipation, low power consumption |
Install insulation boxes, local heating, prevent cold condensation |
| Installation |
Keep away from heat sources, add heat insulation plates |
Avoid exposure to wind and snow, wrap with thermal insulation materials |
