LV600 Series(PA Non‑Explosion‑Proof type)

LV600 Series(PA Non‑Explosion‑Proof type)
LV600 Series(PA Non‑Explosion‑Proof type) LV600 Series(PA Non‑Explosion‑Proof type)

Large Image :  LV600 Series(PA Non‑Explosion‑Proof type)

Product Details:
Place of Origin: CHINA
Brand Name: NBSANMINSE
Certification: ISO
Model Number: LV600 Series(PA Non‑Explosion‑Proof type)
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negotiate
Packaging Details: Box
Delivery Time: 5-30days
Payment Terms: L/C,T/T
Supply Ability: 10000PCS
Contact Now

LV600 Series(PA Non‑Explosion‑Proof type)

Description
APPLICATION ENVIRONMENT: Indoor/Outdoor INSTALLATION: Any Position
IP RATED: IP65 Control Mode: Single Coil
Function Type: 5/3 Closed Center VOLTAGE: 24VAC

Introduce:

LV600 series solenoid valve, solenoid valve are suitable for use in conjunction with pneumatic control valve and piston actuator in most of process production. On this occasion, the solenoid valve only plays an auxiliary function, but it is very important. Especially in the process production chain, the solenoid valve plays a very important role, such as the gas source effectively controls the opening and close state of the process valve. When process production safety requires for valve action, most of them need to be controlled by solenoid valves. It is widely used in oil, natural gas and chemical industry and can also meet the application requirements of fast response and high-frequency service life on industrial automation control systems.

Features:

IEC61508 functional safety standard compliance, TÜV certified Safety Integrity Level SIL3
Static sealing design
Free direction for solenoid operator or four fixed directions
Manual operators available
Explosion-proof Non-explosion-proof operator
External/Internal pilot available
Threaded port connections and NAMUR interface

Function:

LV600 Series(PA Non‑Explosion‑Proof type)

Technical Specifications:

ITEM Single electronic control/dual electronic control
PILOT CATEGORY Pilot type
MEDIA Air/lnert Gas
AMBIENT TEMPERATURE RANGES -60℃~60℃
MEDIA TEMPERATURE -60℃~60℃
OPERATING PRESSURE DIFFERENTIAL 29 to 145 psi(2.0 to 10 bar)
FLOW COEFFICIENT  1.11Cv(1.06Kv)m³/h15.92Kw/m-in1/4"
 3.85Cv(3.30Kv)m³/h55.00Kw/m-in1/2"
 1.11Cv(1.06Kv)m³/h15.92Kw/m-in1/4”
 3.85Cv(3.30Kv)m³/h55.00Kw/m-in1/2"
VALVE CONSTRUCTION Spoo Structure or Jacket structure
BODY MATERIAL Aluminium/Stainless Steel
APPLICATION ENVIRONMENT Indoor/Outdoor
INSTALLATION Any Position
IP RATED IP65
EXPLOSION PROOF APPROVALS Ex db IIC T6Gb Ex mb tb IIIC T80℃

Solenoid Operators:

CLASS OF INSULATION WATT RATING POWER CONSUMPTION
DC WATTS AC WATTS
(VA) VA HOLDING
F 3~6.5W 2.5~6.5W
Standard Voltage 24V,36V,48V,110V 24V, 110V, 220V AC/50Hz, 60Hz

LV600 PBA NFC SC 14NG 5 2 ST * 24VDC

PRODUCT SERIES LV600 SERIES LV600
Valve body form and material PBA Pilot type aluminum alloy material
PBS Pilot type stainless steel material
COIL CATEGORY NFC Coil with terminal box
Control mode SC Single coil
DC Double coil
Air connection 14NG 1/4NPT pipe type
14NB 1/4NPT Namur Type
38NG 3/8NPT pipe type
38NB 3/8NPT Namur Type
12NG 1/2NPT pipe type
12NB 1/2NPT Namur Type
14G 1/4G pipe type
14GB 1/4G Namur Type
38G 3/8G pipe type
38GB 3/8G Namur Type
12G 1/2G pipe type
12GB 1/2G Namur Type
12B 1/2G Namur Type

Customizable threads
Function type 3  3 Port 2 Position
5  5 Port 2 Position
35P 5/3 pressure center
35C 5/3 closed center
35E 5/3 exhaust center
Manual Operator 1  Without manual operation
2  With manual operation
Temperature ST (- 20℃~+60℃)
OL (- 40℃~+60℃)
Special * Special on Request
VOLTAGE 24VDC
110VDC
24VAC
220VAC

Special options are available upon the equipment.

Refer to the product datasheet for details.
