Magnetically Coupled SMC Rodless Air Cylinder Pneumatic Cylinder Slide Type
Contact Person : Ina Chen
Phone Number : 0086-15168536055
WhatsApp : +008615168536055
|Minimum Order Quantity :||20||Price :||Negotiation|
|Packaging Details :||Plastic Bags , Boxes , Carton , Pallet or As Customer Advice||Delivery Time :||Negotiation|
|Payment Terms :||L/C, T/T, Western Union||Supply Ability :||Negotiation|
|Place of Origin:||China||Brand Name:||NBSANMINSE|
|Fluid:||Air||Action:||Double Acting , Single Acting|
|Temperature:||- 10 To 60 ℃||Repeatability:||± 0 . 01 Mm|
|Lubrication:||Not Required||Auto Switch:||Solid State Auto Switch|
smc locking cylinder,
guided pneumatic cylinder
Professional MHC2 Angular Air Gripper , Pneumatic Parallel Gripper
|Operating Pressure||Double Acting||0 . 1 to 0 . 6 MPa|
|Single Acting||0 . 25 to 0 . 6 MPa|
|Ambient and fluid temperature||- 10 to 60 ℃|
|Repeatability||± 0 . 01 mm|
|Max . Operating Frequency||180 c . p . m|
|Action||Double Acting , Single Acting|
|Auto Switch ( Option ) note )||Solid sate auto switch ( 3 – wire , 2 – wire )|
Note ) Refer to pages 807 to 856 for further information on auto switches .
|Action||Model||Bore Size ( mm )||Gripping moment ( N ` m ) ( Effective value ) 1||Opening / Closing angle ( Both Sides )||
Weight ( 2 )
( g )
|Double acting||MHC2 – 10D||10||0 . 01||30 ° to -10 °||39|
|MHC2 – 16D||16||0 . 39||91|
|MHC2 – 20D||20||0 . 70||180|
|MHC2 – 25D||25||1 . 36||311|
|Single acting||MHC2 – 10S||10||0 . 070||30 ° to -10 °||39|
|MHC2 – 16S||16||0 . 31||92|
|MHC2 – 20S||20||0 . 54||183|
|MHC2 – 25S||25||1 . 08||316|
Note 1 ) At the pressure of 0 . 5 MPa .
Refer to “ Effective Gripping Force “ dasta on page 679 for gripping force of each gripping point .
Note 2 ) Except auto switch
Why choose us
1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .
3: Customize according to your special request .
4: Provide free products information .
5: Reliable quality assured and active after-sell service
6: One year quality guarantee
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your delivery date ?
A: It depends on the number of orders . Delivery date is 7 - 30 days .if small order,pls buy from our aliexpress shop, If you need emergency products , we can speed up the production of the first arrangement .
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: Can the product be made with our logo and brand ?
A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization for work.
