Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper

Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper
Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper
Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper

Large Image :  Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper

Product Details:
Place of Origin: China
Brand Name: NBSANMINSE
Certification: ISO9001
Model Number: MHW2
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negotiation
Packaging Details: Box
Delivery Time: 5-30days
Payment Terms: L/C,T/T
Supply Ability: 10000PCS
Contact Now

Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper

Description
Fluid: Air Pressure: 0.15 To 0.7 MPa
Temperature: - 10 To 60 ℃ Lubrication: Not Required
Action: Double Acting Auto Switch: Solid State Auto Switch （3 - Wire , 2 - Wire）
Highlight:

smc locking cylinder

,

smc air cylinders

MHW2 Series 180 ° Angular Type Air Gripper Rack & Pinion Type SMC Similar Air Gripper





Specifications



Fluid Air
Operating Pressure 0.15 to 0.7 MPa
Ambient and fluid temperature - 10 to 60 ℃
Repeatability ±0.2mm
Max . operating frequency

φ20 , 25 : 60 C.P.M.

φ32 to 50 : 30 C.P.M.
Lubrication Not required
Action Double Acting
Auto switch ( Option ) Solid state auto switch (3-wire , 2-wire)



How to Order



Number of fingers

2 : 2 fingers



Bore Size :

20 : 20mm

25 : 25mm

32 : 32mm

40 : 40mm

50 : 50mm



Port thread type



Symbol Type Size
Nil M Thread φ20 , φ25
RC

φ32

φ40

φ50
TN NPT
TF G



Action

D : Double Acting



Finger option

Nil : Flat type fingers ( Standard )

1 : Right angle type fingers tapped mounting



Auto switch

Nil : Without auto switch ( Built - in magnet )



Number of auto switches

Nil : 2 pcs.

S : 1pc.

n : n pc.



Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper 0Double Acting Pneumatic Air Cylinder Gripper 180° Angular Type Rack & Pinion Type Parallel Jaw Gripper 1
