50L Magnehelic Digital Oil Filled Air Pressure Gauge SM2SS With Clear To Read
Technical Specification Table
| NORMAL TWO PIECE SCREWED CONNECTION STAINLESS STEEL CASE PRESSURE GAUGE |
SM2SS |
| Application |
Extreme corrosive and severe environment. It is
used on pneumatic control system, control panel,
pressure regulator, valve positioner, analyzer,
pneumatic actuator, etc. Idustries coverage are as
Oil&Gas On&Offshore, power plants, steel
mining, process, pulp and paper water.
|
| Features |
Accuracy class 2.5,class 1.6, Wide range vibration application
Stainless steel case design, Knock-down system back and front flange
Two piece screwed connection design, Over pressure up to 30% of Full Scale
Restrictor screw standard, Excellent vibration resist with liquid filling
Design scale ranges up to 600 bar
|
Technical Specification
Nominal Size : 40 , 50 , 63 ,75 ,100 and 150mm
Accuracy Class : Class 2 . 5 , Class 1 . 6 ( ≥ 100mm )
Ingress Protection. : IP65
Connection Size : G1 / 8 , G 1 / 4 , G1 / 2 or NPT or others
Scale Rang : Pressure 0 .. 600 bar , Vacuum - 1 bar .. 0 , Compound - 1 .. 24 bar
Filling : Dry or liquid filled
Tube Element Shape : P ≤ 100 bar in C tube , P ＞ 100 bar in helicoil
Operating Temperature : Ambient temperature – 10 ° .. + 70 ° C , Medium temperature 90 ° C Max.
Temperature Error : Additional error when pressure element tmperature
deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling
Over Pressure Limit : 130 % of F . S . P ≤ 100 bar , 115 % of F . S . P ＞ 100bar
Dial Graduation : Black graduation on white for single range, Black and red graduation on white for dual ranges
Design Material
Casing and Bezel Ring : Stainless steel 316L ( SM2SS )
Sensing Element : Stainless steel 316L ( SM2SS )
Connection : Stainless steel 304 ( SM2SS )
Window : Plastic
Window gasket : Industrial rubber seal
Pointer : Black painted aluminium
Dial Plate : Aluminium alloy
Why choose us
1: Sample order & small quantity order is acceptable .
2: Customize according to your special request .
3: Provide free products information .
4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee
FAQ
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Specific application fields:
Industrial process control and measurement: mechanical pressure gauges are widely used in industrial processes due to their high strength and easy production characteristics, and are used to monitor the pressure in equipment and pipelines to ensure production safety.
Utility systems: e.g., monitoring and controlling pressure in piping in water and gas supply systems.
Petrochemical and metallurgy: pressure gauges are used to measure and control the pressure of medium in the production process of petroleum, chemical and metallurgy departments.
Transportation: During vehicle maintenance, the oil pressure gauge is used to monitor the engine oil pressure, and other pressure gauges in the vehicle are also used for tires, etc.
Energy field: in thermal pipe network and power station, pressure gauge is an important tool for monitoring boiler water pressure and system pressure.
Food and pharmaceutical industry: use special pressure gauges, such as diaphragm pressure gauges, to measure the pressure of sensitive media, prevent contamination, and meet sanitary and explosion-proof requirements
