High Performance Submersible Level Transmitter 24VDC For Level Field

High Performance Submersible Level Transmitter 24VDC Power Supply For Level Field

Technical Specification Table

SMPB86 SERIES SUBMERSIBLE HYDROSTATIC LEVEL TRANSMITTER :

SMPB860 / A

Accuracy :

0.5%F S(including linearity . Hysteresis and repeatability

Measuring Range :

0... 1mH₂O to 0...1500mH₂O

Linearity :

Superior to 0.5%F S

Response time :

≤10ms

Power supply :

24VDC

Output :

4 to 20mA 2-wires

Operating Temp :

-10 to +70℃

Compensated Temp :

-10 to +70℃

Storing Temp ;

-40 to +125℃

Wetted parts :

SS304

Diaphragm material :

SS316L

Breathing cable material :

Polythene

Weight :

Stainless steel pipe:G1=300g, breathing cable:G2=65g/m, junction box:G3

Gross weight :

G=G1+G2*length(m)+G3

Power Consume :

<0.5W(24VDC)

Why choose us

1: Customize according to your special request .
2: Provide free products information .

3: High quality with competitive price .

4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee

FAQ

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
