SMF 10 1/4 G NPT Air Compressor Pressure Switch For Easy Mounting Of Valve And Gauges Air Pressure Switch NBSANMINSE
Contact Person : Ina Chen
Phone Number : 0086-15168536055
WhatsApp : +8615168536055
| Place of Origin: | china | Brand Name: | NBSANMINSE |
|---|---|---|---|
| Model Number: | PC58 |
|
Detail Information |
|||
| Features: | With Two Pressure Set Points In One Switch | Model: | PC58 |
|---|---|---|---|
| Size: | G 1-4 NPT 1-4 UF 7-16 M 12X1.25 | Certification: | CE |
| Material: | Copper | Temperature: | -20 ~ 110 C |
Product Description
Ex : ON :1Bar OFF:2Bar =NC
ON :2Bar OFF:1Bar =NO
ON :-0.9Bar OFF:-0.65Bar =NO
ON :-0.65Bar OFF:-0.9Bar =NC
|
Electrical Function
|
B-C
|
D
|
||
|
Rated Amps .(A)Rated Voltage (V)
|
125VAC
|
250VAC
|
24VDC
|
250VAC
|
|
Full Load
|
20A
|
10A
|
8A
|
50VA
|
|
Locked Roter
|
72A
|
72A
|
64A
|
4A
|
|
Temperature
|
-20~110℃
|
|||
Specification
|
Model
|
Press Side
|
Range (Bar)
|
Differential(Bar)
|
Factory Setting (Bar)
|
Max Operating Pressure(Bar)
|
|||
|
Min
|
Max
|
Min
|
Max
|
OFF
|
ON
|
|||
|
PC5832
|
Low Side
|
-0.2
|
7.5
|
0.7
|
4
|
4
|
2
|
20
|
|
High Side
|
8
|
32
|
Fixed 4
|
20
|
15
|
35
|
||
|
PC5832HM
|
Low Side
|
-0.2
|
7.5
|
0.7
|
4
|
4
|
2
|
20
|
|
High Side
|
8
|
32
|
Fixed 4
|
20
|
Manual Reset
|
35
|
||
|
PC5832HLM
|
Low Side
|
-0.2
|
7.5
|
Fixed 4
|
3
|
Manual Reset
|
20
|
|
|
High Side
|
8
|
32
|
Fixed 4
|
20
|
Manual Reset
|
35
|
||
