IP44 Brass Connection Liquid Filled Water Pressure Gauge 63mm 75mm 100mm 160mm

Minimum Order Quantity : 20 Price : Negotiation
Packaging Details : Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice Delivery Time : 5 - 30 Work Days
Payment Terms : L/C, T/T, Western Union Supply Ability : Negotiation
Place of Origin: China Brand Name: Mkfale
Model Number: SMSBD

Detail Information

Nominal Size: 63 , 75 , 100 , 160 Accuracy Class: Class1 . 6 , Class2 . 5 ( Φ 63 , 75 Mm )
Ingress Protection: IP44 Connection: G3 / 8 , G1 / 4 , G1 / 2 , Or NPT Or Others
Temperature: -10 ℃ ~ + 70 ℃ Material Sensing Element: Capsule Type , Copperally
Filling: Dry Type Connection Material: Brass
High Light:

liquid filled pressure gauge


industrial pressure gauge

Product Description

Brass Connection Stainless Steel Pressure Gauge , Liquid Filled Water Pressure Gauge




Technical Specification Table





SMSBD Stainless Steel Case & Brass Connection




SMSSD Series is a premium capsule gauge designed for use in low pressure measurement on
extreme corrosive and severe environment. It is non fillable design and by removing the
bezeiring coulb access to zero adjustment zeroing screw on the front dial in replace of
adjustable pointer. Most popular in use in all industries such as process,mining,machine
tools,power plant,steel mills,pulp & paper,water & sewage and petrochemical plants.




Accuracy class 1.6, Interna calibration Device(ICD)
All stainless steel material,Blow-out-back, Knock-down system back and front flange
DIN case,bayonet lock design, Over pressure up to 30% of Full Scale
Restrictor screw standard, Standard dial unit ranges
Scale ranges -600..0,0..10 to 1000Mbar


Technical Specification :


Nominal Size : 63,75,100 and 160mm

Accuracy Class : Class 1.6,Class 2.5(Φ63,75mm)

Ingress Protection. : IP4

Connection Size : G3/8 , G1/4,G1/2 or NPT or others

Scale Range : Pressure 0..16 to 0..1000 mbar, *Φ63,75mm min range 16mbar

Vacuum -600 mbar..0, Campund -200..+400 mbar

Filling : Dry type

Tube Element Shape : Capsule type diaphragm tube

Operating Temperature : Ambient temperature -10° ..+70℃, Medium temperature 90℃ Max.

Temperature Error : Additional error when pressure element tmperature deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling

Over Pressure Limit : 130% of Full Scale

Dial Graduation : Black graduation on white for single range, Black and red graduation on white for dual ranges


Design Material :

Casing and Bezel Ring : SS304

Sensing Element : Capsule type,SS316L

Connection : SS316L

Window : Plain instrement glass

Window gasket : Industrial rubber seal

Pointer : Black painted aluminium

Dial Plate : Aluminium alloy


Why choose us

1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .

3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .




Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
