|Place of Origin:||China|
|Minimum Order Quantity:||20|
|Packaging Details:||Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice|
|Delivery Time:||5 - 30 Work Days|
|Payment Terms:||L/C, T/T, Western Union|
|Nominal Size:||40 , 50 , 63 ,75 ,100 And 150mm||Accuracy Class:||Class 2.5,Class 1.6(≥100mm)|
|Connection Size:||G1 / 8 , G1 / 4 ,G1 / 2 Or NPT Or Others||Filling:||Dry Or Liquid Filled|
|Connection:||Stainless Steel 304||Window:||Plastic|
liquid filled pressure gauge,
stainless steel pressure gauge
Precision Stainless Steel Pressure Gauge Normal Two Piece Screwed Connection
Technical Specification Table
|NORMAL TWO PIECE SCREWED CONNECTION STAINLESS STEEL CASE PRESSURE GAUGE||SM2SS|
Extreme corrosive and severe environment. It is
used on pneumatic control system, control panel,
pressure regulator, valve positioner, analyzer,
pneumatic actuator, etc. Idustries coverage are as
Oil&Gas On&Offshore, power plants, steel
mining, process, pulp and paper water.
Accuracy class 2.5,class 1.6, Wide range vibration application
Stainless steel case design, Knock-down system back and front flange
Two piece screwed connection design, Over pressure up to 30% of Full Scale
Restrictor screw standard, Excellent vibration resist with liquid filling
Design scale ranges up to 600 bar
Nominal Size :
40 , 50 , 63 ,75 ,100 and 150mm
Accuracy Class :
Class 2 . 5 , Class 1 . 6 ( ≥ 100mm )
Ingress Protection. :
Connection Size :
G1 / 8 , G 1 / 4 , G1 / 2 or NPT or others
Scale Rang :
Pressure 0 .. 600 bar , Vacuum - 1 bar .. 0 , Compound - 1 .. 24 bar
Dry or liquid filled
Tube Element Shape :
P ≤ 100 bar in C tube , P ＞ 100 bar in helicoil
Operating Temperature :
Ambient temperature – 10 ° .. + 70 ° C , Medium temperature 90 ° C Max.
Temperature Error :
Additional error when pressure element tmperature
deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling
Over Pressure Limit :
130 % of F . S . P ≤ 100 bar , 115 % of F . S . P ＞ 100bar
Dial Graduation :
Black graduation on white for single range, Black and red graduation on white for dual ranges
Casing and Bezel Ring :
SS316L ( SM2SS )
Sensing Element :
SS316L ( SM2SS )
SS304 ( SM2SS )
Window gasket :
Industrial rubber seal
Black painted aluminium
Dial Plate :
Why choose us
1: Large stock for fast shipping .
2: High quality with competitive price .
3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
