SM2SB 40B / L Liquid Filled Water Pressure Gauge With Two Screwed Connection

Minimum Order Quantity : 20 Price : Negotiation
Packaging Details : Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice Delivery Time : 5 - 30 Work Days
Payment Terms : L/C, T/T, Western Union Supply Ability : Negotiation
Place of Origin: China Brand Name: Mkfale
Model Number: SM2SB 40B / L

Detail Information

Nominal Size: 40 Mm Accuracy Class: Class 2 . 5
IP: IP65 Connection Size: G1 / 8 Or NPT Or Others
Filling: Dry Or Liquid Filled Connection: Brass
High Light:

stainless steel pressure gauge


industrial pressure gauge

Product Description

SM2SB 40B / L Liquid Filled Water Pressure Gauge Normal Two Piece Screwed Connection




Technical Specification Table




Applicable for pneumatic and hydraulic


sprinkles system,building automation

system and processing unit where

vibration is concern.


Accuracy class 2.5,class 1.6, Wide range vibration application

Stainless steel case design, Knock-down system back and front flange

Two piece screwed connection design, Over pressure up to 30% of Full Scale

Restrictor screw standard, Excellent vibration resist with liquid filling

Design scale ranges up to 600 bar

Technical Specification Nominal Size 40, 50, 63,75,100 and 150mm
Accuracy Class Class 2.5,Class 1.6(≥100mm)
Ingress Protection. IP65
Connection Size G1/8,G1/4,G1/2 or NPT or others
Scale Range Pressure 0..600 bar, Vacuum -1 bar..0, Compound -1..24 bar
Filling Dry or liquid filled
Tube Element Shape P≤100 bar in C tube, P>100 bar in helicoil
Operating Temperature Ambient temperature -10° ..+70° C, Medium temperature 90° C Max.
Temperature Error

Additional error when pressure element tmperature

deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling

Over Pressure Limit 130% of F.S.P ≤100 bar, 115% of F.S.P >100bar
Dial Graduation Black graduation on white for single range, Black and red graduation on white for dual ranges
Design Material Casing and Bezel Ring Copper alloy(SM2SB)
Sensing Element Copper alloy(SM2SB)
connection Brass(SM2SB)
Window Plastic
Window gasket Industrial rubber seal
Pointer Black painted aluminium
Dial Plate Aluminium alloy


Why choose us


1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .




Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
