SMPB860 Series Submersible Level Transmitter Stainless Steel Wetted Parts

Large Image : SMPB860 Series Submersible Level Transmitter Stainless Steel Wetted Parts

Product Details:

Place of Origin:	CHINA
Brand Name:	Mkfale
Certification:	ISO9001
Model Number:	SMPB860

Payment & Shipping Terms:

Minimum Order Quantity:	20
Price:	Negotiate
Packaging Details:	Box
Delivery Time:	5-30days
Payment Terms:	L/C,T/T
Supply Ability:	10000PCS

Contact Now

SMPB860 Series Submersible Level Transmitter Stainless Steel Wetted Parts

Description

Accuracy:	0 . 5 % F S	Measuring Range:	0 ... 1mH2O To 0 ... 1500mH2O
Linearity:	Superior To 0 . 5 % F S	Response Time:	≤ 10ms
Power Supply:	24VDC	Output:	4 To 20mA 2 - Wires
Highlight:	high accuracy pressure transmitter , differential pressure transmitter

SMPB860 Series Submersible Hydrostatic Level Transmitter Stainless Steel Wetted Parts

Technical Specification Table

SMPB86 SERIES SUBMERSIBLE HYDROSTATIC LEVEL TRANSMITTER	SMPB860
Accuracy	0.5%F S(including linearity.Hysteresis and repeatability
Measuring Range	0... 1mH₂O to 0...1500mH₂O
Linearity	Superior to 0.5%F S
Response time	≤10ms
Power supply	24VDC
Output	4 to 20mA 2-wires
Operating Temp	-10 to +70℃
Compensated Temp	-10 to +70℃
Storing Temp	-40 to +125℃
Wetted parts	SS304
Diaphragm material	SS316L
Breathing cable material	Polythene
Weight	Stainless steel pipe:G1=300g, breathing cable:G2=65g/m, junction box:G3
Gross weight	G=G1+G2*length(m)+G3
Power Consume	<0.5W(24VDC)

Why choose us

1: Customize according to your special request .
2: Reliable quality assured and active after-sell service

3: Various style for each products and completely series industry instruments.
4: Large stock for fast shipping .
5: 12-18month quality guarantee

FAQ

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .

Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
