SM1SP - 63mm L / B Liquid Filled Pressure Gauge For Extreme Vibration Application

Minimum Order Quantity : 20 Price : Negotiation
Packaging Details : Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice Delivery Time : 5 - 30 Work Days
Payment Terms : L/C, T/T, Western Union Supply Ability : Negotiation
Place of Origin: China Brand Name: Mkfale
Model Number: SM1SP

Detail Information

Thread Size: 1 / 4 " Nominal Size: 63 Mm
Accuracy Class: Class 1 . 6 Ingress Protection: IP65 ( Weather Tight )
Connection Size: G1 / 4 Filling: Dry Or Liquid Filled
High Light:

liquid filled pressure gauge

,

stainless steel pressure gauge

Product Description

SM1SP - 63mm L / B Liquid Filled Pressure Gauge For Extreme Vibration Application







ONE PIECE CONNECTION STAINLESS STEEL CASE DESIGN
SM1SP One piece connection with crimped case design

Application :
A special design with stainless steel case and copper alloy wetted part and fillable option for
extreme vibration aplication and non-corrosive ambient field condition,with bayonet lock
case design.applicable for pneumatic and hydraulic systems, compressors, engines, pumps,
sprinkles system,building automation system and processing unit where vibration is
concern.

Features :
Accuracy class 1.6,class 1.0, Wide range vibration application
Stainless steel case design, Knock-down system back and front flange
Crimped lock case design, Over pressure up to 30% of Full Scale
Restrictor screw standard, Excellent vibration resist with liquid filling
Design scale ranges up to 600 bar

Technical Specification :

Nominal Size : 63,100 150mm

Accuracy Class : Class 1.6,Class 1.0(Φ>100mm)

Ingress Protection. : IP65 (Weather tight)

Connection Size : G1/4,G1/2 or NPT

Scale Range : Pressure 0..1000 bar, Vacuum -1 bar..0, Compound -1..24 bar
Tube Element Shape : P≤100 bar in c tube, P>100 bar in helicoil

Filling : Dry or liquid filled

Operating Temperature : Ambient temperature -10° ..+70° C, Medium temperature 90° C Max.
Temperature Error : Additional error when pressure element tmperature deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling

Over Pressure Limit : 130% of F.S.P≤100 bar, 115% of F.S.P>100bar




Design Material Casing and Bezel Ring Casing and Bezel Ring, SS304
Sensing Element Copper alloy
connection Brass
Window Plastic(SM1SP Series)
Window gasket Industrial rubber seal
Pointer Black painted aluminium
Dial Plate Aluminium alloy


Mounting Code
L:Bottom entry, W:Bottom with back flange, B:Back entry(centre-back,cower-back)
F:Back with front flange, Z:Back with bracket




Why choose us


1: Various style for each products and completely series pneumatic products .
2: High quality with competitive price .
3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .
5: Provide free products information .


FAQ

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .


Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.


SM1SP - 63mm L / B Liquid Filled Pressure Gauge For Extreme Vibration Application 0
