Laser Welding Stainless Steel Pressure Gauge , SMSS - 100mm 4 Inch Bottom Back Entry Small Pressure Gauge

Laser Welding Type Stainless Steel Pressure Gauge , SMSS - 100mm 4 Inch Bottom Back Entry Small Pressure Gauge

Technicasl Specification Table

LASER WELDING ALL STAINLESS STEEL PRESSURE GAUGE SMSS

Application :

SMSS Series is a premium design pressure gauge with fully stainless steel construction,liquid

fillable and with various option used in extreme corrosive & severe environment.SMSS Series

can be i ncorporate with most accessories such as Diaphragm chemical

seal,Siphon,dampener,etc.. to fur ther extend it usages.commonly,uses in Process

industries,Mining,Power plants,Steel mills,Pulp & Paper,Water & Sewage,Petrochemical

plants,etc..

Features :

Accuracy class 1.0, Wide range application

All stainless steel construction, Knock-down system back and front flange

Bayonet lock case design, Over pressure up to 30% of Full Scale

Restrictor screw standard, Excellent vibration resist with liquid filling

Design scale ranges up to 600 bar

Technical Specification

Nominal Size :

63,100,150,200 and 250mm

Accuracy Class :

Class 1.0

Ingress Protection . :

IP65(Weather tight

Connection Size :

G1/4,G1/2 or NPT or others

Scale Range :

Pressure 0..600 bar(SMSS Series), Vacuum -1 bar..0, Compound -1..24 bar

Filling :

Dry or liquid filled

Tube Element Shape :

P≤100 bar in c tube, P＞100 bar in helicoil

Operating Temperature :

Ambient temperature -10° ..+70° C, Medium temperature 70° C Max.

Temperature :

Additional error when pressure element tmperature

deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling

Over Pressure Limit :

130% of F.S.P≤100 bar, 115% of F.S.P＞100bar

Dial Graduation :

Black graduation on white for single range, Black and red graduation on white for dual ranges

Design Material :

Casing and Bezel Ring :

SS304

Sensing Element :

SS316L

Connection :

SS316L

Window :

Plain instrement glass or laminated glass

Window gasket :

Industrial rubber seal

Pointer :

Black painted aluminium

Dial Plate :

Aluminium alloy

Mounting Code :

L:Bottom entry, W:Bottom with back flange, B:Back entry

F:Back with front flange, Z:Back with bracket

Why choose us

1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .

5: Reliable quality assured and active after-sell service

Q: Could you offer the free samples ?

A: Yeah, but it depends products, Pls contact us ina@pneuhydr.com or whatsapp 0086 15168536055

Q: What ' s your business scope ?

A: Our business scope is service of exporter automation parts with full container, and sell air cylinder , air source treatment , solenoid valve , air valve, motorize valve , Brass valve, hydraulic valve, hydraulic cylinder,  air and oil fitting, pressure gauge etc .

Q: What types of products you can make ?

A: We can make many kinds of stainless steel, brass ,aluminum materials processing .like high pressure Valve / solenoid valve / electric valve / water valve/pneumatic valve/air cylinder/hydraulic valve/hydraulic accumulator products and so on .

Q: Can the product be made with our logo and brand ?

A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization if it is possible .

Q:Can you provide original famous pneumatic and hydraulic,instruments brand goods ?

A: Yes,We can supply like Festo,Smc,Ckd,Burket,Hydac,Rexroth,Siemens,Rosemount,Marsh ,Endress+Hauser etc.

Q: Is there a warranty available?

A: Yes, normally products is one year quality guarantee.

Q: Is the connector in British or Metric system? What is the difference between PT, NPT, and G threads?

A: The G thread is cylindrical and does not seal itself, requiring additional gaskets to prevent leakage. PT and NPT are conical, and the internal and external threads become tighter and tighter when tightened. Sealing is achieved through the deformation of the threads, and sealant or tape is usually used in conjunction to enhance the sealing effect

G-thread is a cylindrical straight pipe used for non sealed connections; PT thread is a conical tube that relies on the deformation and sealing of the thread itself; NPT is also a conical tube with a tooth profile angle of 60 degrees, mainly used in North America

Q: How to convert pressure units: MPa, bar, psi, kg/cm ²?

A: 1MPa=10bar≈145psi≈10kg

Q:What usually causes the burnout of solenoid valve coils?

A:Incorrect voltage and hz, frequent switching, pilot head entering liquid,valve core and spring problem,environment hot,heavy vibration etc.
