Brass Connection Liquid Filled Pressure Gauge With Bayonet Case

Large Image : Brass Connection Liquid Filled Pressure Gauge With Bayonet Case

Product Details:

Place of Origin:	CHINA
Brand Name:	Mkfale
Certification:	ISO9001
Model Number:	SM1SB

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiate
Packaging Details:	Box
Delivery Time:	5-30days
Payment Terms:	L/C,T/T
Supply Ability:	10000PCS

Contact Now

Brass Connection Liquid Filled Pressure Gauge With Bayonet Case

Description

Nominal Size:	63 , 100 , 150mm	Accuracy Class:	Class1 . 6 , Class1 . 0 ( Φ ＞ 100 Mm ）
Connection Size:	G1 / 4 , G1 / 2 , Or NPT	Sensing Element:	Copper Alloy
Connection:	Brass	Window:	Tempered Glass ( SM1SB )
Highlight:	liquid filled pressure gauge , stainless steel pressure gauge

Brass Connection Liquid Filled Pressure Gauge With Bayonet Case Design

SM1SB One Piece Connection With Bayonet Case Design ,
SM1SP One Piece Connection With Crimped Case Design ,
SM2SB , SM2SS , SMSS , SMSSH , SMSS - 160L

ONE PIECE CONNECTION STAINLESS STEEL CASE DESIGN		SM1SB One piece connection with bayonet case design
Application		A special design with stainless steel case and copper alloy wetted part and fillable option for extreme vibration aplication and non-corrosive ambient field condition,with bayonet lock case design.applicable for pneumatic and hydraulic systems, compressors, engines, pumps, sprinkles system,building automation system and processing unit where vibration is concern.
Features		Accuracy class 1.6,class 1.0, Wide range vibration application Stainless steel case design, Knock-down system back and front flange Crimped lock case design, Over pressure up to 30% of Full Scale Restrictor screw standard, Excellent vibration resist with liquid filling Design scale ranges up to 600 bar
Technical Specification	Nominal Size	63,100 150mm
	Accuracy Class	Class 1.6,Class 1.0(Φ>100mm)
	Ingress Protection.	IP65 (Weather tight)
	Connection Size	G1/4,G1/2 or NPT
	Scale Range	Pressure 0..1000 bar, Vacuum -1 bar..0, Compound -1..24 bar
	Tube Element Shape	P≤100 bar in c tube, P＞100 bar in helicoil
	Filling	Dry or liquid filled
	Operating Temperature	Ambient temperature -10° ..+70° C, Medium temperature 90° C Max.
	Temperature Error	Additional error when pressure element tmperature deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling
	Over Pressure Limit	130% of F.S.P≤100 bar, 115% of F.S.P＞100bar
	Dial Graduation	Black graduation on white for single range, Black and red graduation on white for dual ranges
Design Material	Casing and Bezel Ring	Casing and Bezel Ring, SS304
	Sensing Element	Copper alloy
	connection	Brass
	Window	Tempered glass(SM1SB Series), Plastic(SM1SP Series)
	Window gasket	Industrial rubber seal
	Pointer	Black painted aluminium
	Dial Plate	Aluminium alloy
Mounting Code		L:Bottom entry, W:Bottom with back flange, B:Back entry(centre-back,cower-back) F:Back with front flange, Z:Back with bracket

Specific application fields:
Industrial process control and measurement: mechanical pressure gauges are widely used in industrial processes due to their high strength and easy production characteristics, and are used to monitor the pressure in equipment and pipelines to ensure production safety.
Utility systems: e.g., monitoring and controlling pressure in piping in water and gas supply systems.
Petrochemical and metallurgy: pressure gauges are used to measure and control the pressure of medium in the production process of petroleum, chemical and metallurgy departments.
Transportation: During vehicle maintenance, the oil pressure gauge is used to monitor the engine oil pressure, and other pressure gauges in the vehicle are also used for tires, etc.
Energy field: in thermal pipe network and power station, pressure gauge is an important tool for monitoring boiler water pressure and system pressure.
Food and pharmaceutical industry: use special pressure gauges, such as diaphragm pressure gauges, to measure the pressure of sensitive media, prevent contamination, and meet sanitary and explosion-proof requirements
