SMPB8101 Durable Digital Pressure Transmitter IP65 Stainless Steel Transmitter

Minimum Order Quantity : 20 Price : Negotiation
Packaging Details : Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice Delivery Time : 5 - 30 Work Days
Payment Terms : L/C, T/T, Western Union Supply Ability : Negotiation
Place of Origin: China Brand Name: Mkfale
Model Number: SMPB8101

Detail Information

Storing Temp: - 40 To + 125 ℃ Enclosure Protection: IP65
Wetted Parts: SS304 , SS316L Diaphragm Material: SS316L
Housing Material: Aluminium Power Consume: < 0 . 5W ( 24VDC )
High Light:

pressure transmitter with display

,

differential pressure transmitter

Product Description

SMPB8101 Durable Digital Pressure Transmitter IP65 Stainless Steel Transmitter







Technical Specification Table



SMPB81 SERIES PRESSURE TRANSMITTER :

SMPB8101



Accuracy :

0 . 25 % F S , 0 . 5 % F S ( including linearity . Hysteresis and repeatability )



Measuring Range :

- 1 ... 0bar to - 1...25bar , 0... 0 . 1bar to 0 ... 600bar



Linear :

Superior to 0.25%F S



1 year stability :

Superior to 0.25%F S



Response time :

≤ 10 ms



Power supply :

24VDC (or 12 to 36VDC)



Output :

4 to 20mA(or 0 to 10mA,1 to 5V, 0 to 5V,0 to 10V)



Proof pressure :

150%F S



Burst pressure :

300%F S



Operating Temp :

-20 to +85℃



Compensated Temp :

-10 to +70℃



Storing Temp :

-40 to +125℃



Process connection :

M20*1.5 male or 1/2NPT male



Electric connection :

M20*1.5 male



Enclosure Protection :

IP65



Wetted parts :

SS304 SS316L



Diaphragm material :

SS316L



Housing material :

Aluminium



Power Consume :

<0.5W(24VDC)



Weight :

750g





Why choose us



1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .

3: Reliable quality assured and active after-sell service

4: High quality with competitive price .
5: Sample order & small quantity order is acceptable .





FAQ



Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
