Pressure Transmitter SMJPB2000 Diffused - Silicon Type Pressure Transmitter IP65

Minimum Order Quantity : 20 Price : Negotiation
Packaging Details : Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice Delivery Time : 5 - 30 Work Days
Payment Terms : L/C, T/T, Western Union Supply Ability : Negotiation
Place of Origin: China Brand Name: Mkfale
Model Number: SMJPB2000

Detail Information

Response Time: ≤ 10ms Power Supply: 24VDC ( Or 12 To 36VDC )
Output: 4 To 20mA(Or 0 To 10mA, 1 To 5V,0 To 5V,0 To 10V Proof Pressure: 150%F S
Process Connection: M20*1.5 Male Or 1/2NPT Male Diaphragm Material: SS316L
High Light:

pressure transmitter with display

,

differential pressure transmitter

Product Description

Pressure Transmitter SMJPB2000 Diffused - silicon Type Pressure Transmitter IP65







Technical Specification Table



SMJPB2000 SERIES PRESSURE TRANSMITTER :

SMJPB2000



Accuracy :

0.25%F S,0.5%F S(including linearity.Hysteresis and repeatability



Measuring Range :

-1 ... 0bar to -1...25bar,0... 0.1bar to 0... 600bar



Linear :

Superior to 0.25%F S



1 year stability :

Superior to 0.25%F S



Response time :

≤ 10ms



Power supply :

24VDC (or 12 to 36VDC)



Output :

4 to 20mA(Or 0 to 10mA, 1 to 5V,0 to 5V,0 to 10V



Proof pressure :

150%F S



Burst pressure :

300%F S



Operating Temp :

-20 to +85℃



Compensated Temp :

-10 to +70℃



Storing Temp :

-40 to +125℃



Process connection :

M20*1.5 male or 1/2NPT male



Enclosure Protection :

IP65



Wetted parts :

SS304



Diaphragm material :

SS316L



Power Consume :

<0.5W(24VDC)



Weight :

380g



Why choose us



1: Customize according to your special request .
2: Provide free products information .
3: Reliable quality assured and active after-sell service
4: 12-18month quality guarantee



5: Large stock for fast shipping .



FAQ



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
