Durable SMPB84 Series Digital Pressure Transmitter M20 * 1.5 Male Or 1 / 2NPT Male

Product Details:
Place of Origin: China
Brand Name: Mkfale
Model Number: SMPB84
Payment & Shipping Terms:
Minimum Order Quantity: 20
Price: Negotiation
Packaging Details: Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice
Delivery Time: 5 - 30 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: Negotiation

Detail Information

Accuracy: 0.25%F S,0.5%F S(including Linearity.Hysteresis And Repeatability Measuring Range: -1 ... 0bar To -1...25bar,0... 0.1bar To 0... 600bar
Linear: Superior To 0.25%F S Response Time: ≤ 10ms
Output: 4 To 20mA Wetted Parts: SS304
High Light:

pressure transmitter with display

,

high accuracy pressure transmitter

Product Description

Durable SMPB84 Series Digital Pressure Transmitter M20 * 1 . 5 Male Or 1 / 2NPT Male







Technical Specification Table


SMPB84 SERIES PRESSURE
TRANSMITTER
SMPB8400
Accuracy 0.25%F S,0.5%F S(including linearity.Hysteresis and repeatability
Measuring Range -1 ... 0bar to -1...25bar,0... 0.1bar to 0... 600bar
Linear Superior to 0.25%F S
1 year stability Superior to 0.25%F S
Response time ≤ 10ms
Power supply 24VDC (or 12 to 36VDC)
Output 4 to 20mA
Proof pressure 150%F S
Burst pressure 300%F S
Operating Temp -20 to +85℃
Compensated Temp -10 to +70℃
Storing Temp -40 to +125℃
Process connection M20*1.5 male or 1/2NPT male
Enclosure Protection IP65
Wetted parts SS304
Diaphragm material SS316L
Power Consume <0.5W(24VDC)




Why choose us

1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .




FAQ


Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.



Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.


Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
