SMPB8300 / H Series Digital Pressure Transmitter 24VDC Power Supply Plastic
Contact Person : Ina Chen
Phone Number : 0086-15168536055
WhatsApp : +8615168536055
| Minimum Order Quantity : | 20 | Price : | Negotiation |
|---|---|---|---|
| Packaging Details : | Plastic Bags , Boxes , Carton , Pallet Or As Customer Advice | Delivery Time : | 5 - 30 Work Days |
| Payment Terms : | L/C, T/T, Western Union | Supply Ability : | Negotiation |
| Place of Origin: | China | Brand Name: | Mkfale |
|---|---|---|---|
| Model Number: | SMPBS10 |
|
Detail Information |
|||
| Accuracy: | 0 . 5 % F • S 、 0 . 2 % F• S | Measuring Range: | - 0 . 1MPa ~ 0 ; 0 ~ ( 10KPa ~ 60MPa ) 、≤ 0 ~ 0 . 5M Liquid Level |
|---|---|---|---|
| Linear: | Superior To 0 . 2 % F S | Response Time: | ≤ 10mS |
| Power Supply: | 24VDC、12VDC - 36VDC ( Constant Voltage ) | Output: | 4 ~ 20mA |
| Highlight: | high accuracy pressure transmitter,differential pressure transmitter |
||
Product Description
Safety Digital Pressure Transmitter SMPBS10 Series 24VDC , 12VDC - 36VDC Plastic Housing
Technical Specification Table
|
SMPB SERIES PRESSURE TRANSMITTER |
SMPBS10 |
| Accuracy | 0.5%F•S,0.2%F•S |
| Measuring Range | -0.1MPa~0; 0~(10KPa~60MPa) ,≤0~0.5M liquid level |
| Linear | Superior to 0.2%F S |
| 1 year stability | Superior to 0.2%F S |
| Response time | ≤10mS |
| Power supply | 24VDC,12VDC-36VDC(constant voltage) |
| Output | 4~20mA |
| Load(Ω) | 0~600Ω(Rz=(V-12)/0.02 (V is supply voltage) |
| Proof pressure | 150%F S |
| Burst pressure | 300% F S |
| Operating Temp | -20~ +85℃(＜85℃ use radiating tube ) |
| Storing Temp | -20~ +125℃ |
| Process connection | M20×1.5 ,1/2NPT ,1/2BSP or others |
| Enclosure Protection | IP63 |
| Wetted parts | SS304 |
| Diaphragm material | SS316L |
| Electrical Connections | DIN43650 Hersman junction box |
| Housing material | Plastic |
| Power Consume | <0.5W |
| Weight | 250g |
Why choose us
1: High quality with competitive price .
2: Sample order & small quantity order is acceptable .
3: Customize according to your special request .
4: 12-18month quality guarantee
5: Large stock for fast shipping .
FAQ
Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .
Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.
Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .
