Digital Oil Liquid Pressure Level Transmitter 4 - 20 MADC Output , 10 Ms Response Time

Product Description

Digital Oil Liquid Pressure Level Transmitter 4 - 20 MADC Output , 10 Ms Response Time







Technical Specification Table



Accuracy :

0 . 5 % F S



Measuring range :

Liquid Level : 0 ~ 0 . 5 m , up to 1500 m



Temperature :

0 ~ 70 ℃



Linearity :

Superior to 0 . 2 % F S



Temperature drift :

Superior to ± 0 . 03 % F S / ℃



Stability :

Superior to 0 . 5 % F S for 1 year



Response time :

10 ms



Power Supply :

12 to 36 VDC



Output :

4 ~ 20 mADC



Load Resistance :

0 ~ 600 Ω



Liquid Temp :

- 10 ~ 60 ℃



Compensated temp :

- 10 ~ 60 ℃



Storage Temp :

- 40 ~ 125 ℃



Installation Position :

Direct into the bottom of the liquid



Housing material :

304 Stainless steel or 316 Stainless steel



Diaphragm material :

316 Stainless Steel



Breathing Cable :

Polythene or PTFE



Weight :

Stainless Steel Pipe ( G1 ) : about 500 g

Breathing cable ( G2 ) : about 65g / m

Junction box ( G3 ) : above



Gross weight ( G ) :

G = G1 + G2 * length ( m ) + G3



Power Consume :

＜ 0 . 5 W + 0 . 5 W ( 24VDC )



Why choose us

1: Customize according to your special request .
2: Provide free products information .

3: Large stock for fast shipping .
4: Reliable quality assured and active after-sell service
5: 12-18month quality guarantee



FAQ



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .



Q: What ' s your business scope ?
A: High qulaity industry instruments is our business scope .Include Flow meter,Water meter,Manometer,Pressure ,Temperature,Level transimitter and parts.and industry Valve for water,anticorrosion fluid.



Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
