Metering Valve Moderate Pressure Instrument Flow Regulating Needle Valve Straight And Angle

Metering Valve Moderate Pressure Instrument Flow Regulating Needle Valve Straight And Angle Design Long Lifetime

MV Series Features

Forged - body 316 St . St . or Brass Construction

Straight and Angle Patterns

Panel Mounting

MAWP 2000 psig - ( 135 bar )

MAWT 400 ℉ ( 204 ℃ )

Flow coefficients ( Cv ) from 0 . 004 to 0 . 15

Round & Slotted Handles With Screwdriver Slots

Ends , Male & Female NPT ,

Face Seal Bead End Connections

1 ° , 3 ° , and 5 ° Stem Taper for required Flow control

Stem with Stopper Shoulder - Long lifetime

General

The MV Series is a moderate - pressure instrumentation flow - regulating needle valve . It is generally used for instrumentation panels , sampling systems and accurate applications .

The valves are compact in size and structure and offer reliably low and moderate flow regulation with long service life . The MV Series is rated to max . 2000 psig ( 340 bar ) .

Ordering Information

Valve Series : MV = 5 ° , MVA = 1 ° / 3 °

Body and Ends Material : SS = St . St 316 , B = Brass , H = Alloy C276 , M = Monel

End Connection : L = Tube End Type , N = Thread Type

End Connection Size : 1 / 8 " 3mm 1 / 4 " 6mm , 3 / 8 "

Pattern Valve Type : Straight Port Valve , Angle Port Valve

O - ring Material : EP = EPDM / EPM , NE = Neoprene , KZ = Kalrez , BU = Buna - N

Handle Color : G = Green , R = Red , Y = Yellow

Oxygen Clean : OC = Oxygen Clean , LF = Lubricant Free

Why choose us

1: Various style for each products and completely series pneumatic products .
2: Large stock for fast shipping .

3: Sample order & small quantity order is acceptable .
4: Customize according to your special request .

5: Reliable quality assured and active after-sell service

FAQ

Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .

Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .

Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.

Q: What types of service ?
A: Supply technical information for your Working condition and give advise about details.
