TL4330 Zero Voltage Switch Zero Voltage Controller IP65

Large Image : TL4330 Zero Voltage Switch Zero Voltage Controller IP65

Product Details:

Place of Origin:	CHINA
Brand Name:	NBSANMINSE
Certification:	ISO9001
Model Number:	TL4330

Payment & Shipping Terms:

Minimum Order Quantity:	10PCS
Price:	Negotiate
Packaging Details:	Box
Delivery Time:	5-30days
Payment Terms:	L/C,T/T
Supply Ability:	1000V

Contact Now

TL4330 Zero Voltage Switch Zero Voltage Controller IP65

Description

Working Viscosity:	<1×10－3m2/s	Switching Element:	Microswitch
Protection Grade:	IP65	Ambient Temp.:	－20℃～50℃
Medium Temp.:	0～80℃	Repeatability Error:	≤1%
Warranty:	1 Year
Highlight:	IP65 zero voltage switch , zero voltage switch Controller

Overview
The TL4330 zero pressure switch overcomes the common problem of pressure controllers on the market not working when the pressure drops to zero, and is suitable for low pressure alarms in the system.
The TL4330 zero pressure switch uses a diaphragm sensor that can be used for liquid media such as air, gas, water, steam, hydraulic oil, and light fuel. (If the customer uses corrosive gases or liquids, please specify in the ordering requirements.)

Main Technical Performance

Working viscosity	<1×10^－3m²/s
Switching element	microswitch
Protection grade	IP65
Ambient temperature	－20℃～50℃
Medium temperature	0～80℃
Anti-Vibration Performance	20m/s²
Repeatability error	≤1%
Contact capacity	AC 220V 6A(Resistive)

Specifications
Switching difference is not adjustable

Set value adjustment range MPa (KPa)	Switching difference not greater than MPa (KPa)	**Allowable pressure ② MPa (KPa)	Switching frequency/minute	Pressure sensor material		Internal thread of interface	Weight (kg)	Order catalog number
Set value adjustment range MPa (KPa)	Switching difference not greater than MPa (KPa)	**Allowable pressure ② MPa (KPa)	Switching frequency/minute	Casing	Diaphragm	Internal thread of interface	Weight (kg)	Order catalog number
(0～2.5)	(0.2)	(50)	20	brass	Imported membrane	G1/4	1.15	TL4330.70-018066
(0～6)	(0..45)	(50)	20	brass	Imported membrane	G1/4	1.15	TL4330.70-021066
(0～16)	(0.5)	(50)	20	brass	Imported membrane	G1/4	1.15	TL4330.70-023066
(0～25)	(0.6)	(50)	20	brass	Imported membrane	G1/4	1.15	TL4330.70-024066
0.003～0.06	0.004	1.6	20	brass	Imported membrane	G1/4	1.15	TL4330.70-133066
0.006～0.1	0.006	1.6	20	brass	Imported membrane	G1/4	1.15	TL4330.70-142066
0.003～0.16	0.0075	1.6	20	brass	Imported membrane	G1/4	1.15	TL4330.70-134066
0.003～0.25	0.001	1.6	20	brass	Imported membrane	G1/4	1.15	TL4330.70-135066
0.03～0.4	0.02	4	20	brass	Imported membrane	G1/4	1.15	TL4330.70-155066
0.03～0.6	0.03	4	20	brass	Imported membrane	G1/4	1.15	TL4330.70-156066
0.05～1	0.38	4	20	brass	Imported membrane	G1/4	1.15	TL4330.70-166066
0.1～1.6	0.08	5	20	brass	Imported membrane	G1/4	1.15	TL4330.70-175066
0.1～2.5	0.1	5	20	brass	Imported membrane	G1/4	1.15	TL4330.70-178066

TL4330 Zero Voltage Switch Zero Voltage Controller IP65 0
