Hydraulic Stainless Steel Pressure Gauge SMCBS On Non - Corrosive Line
Technical Specification Table
| STEEL CASE CAPSULE GAUGE |
| Application |
A premium capsule gauge designed for use in low pressure measurement on non-corrosive
and gasseous. Structure black steel case or chromed steel case and bezel,app cable for dry
and gaseous that not effect the cupreous metal sensing element. With expanded over
pressure resistance,allowed transient overpressure up to +30% of Full Scale. W dely used in
various industrial applications.
|
| Features |
Accuracy class 1.6,Class 2.5, Interna calibration Device(ICD)
Black steel case material,Blow-out-back, Flanged type back and front flange
DIN case,bayonettlock design, Over pressure up to 30% of Full Scale
Restrictor screw standard, Standard dial unit ranges
Scale ranges -600..0,0..10 to 1000Mbar
|
| Technical Specification |
Nominal Size |
63,75,100 and 160mm |
| Accuracy Class |
Class 1.6,Class 2.5(Φ63,75mm) |
| Ingress Protection. |
IP4 |
| Connection Size |
G3/8,G1/4,G1/2 or NPT or others |
| Scale Range |
Pressure 0..16 to 0..1000 mbar, *Φ63,75mm min range 16mbar
Vacuum -600 mbar..0, Campund -200..+400 mbar
|
| Filling |
Dry type |
| Tube Element Shape |
Capsule type siaphragm tube |
| Operating Temperature |
Ambient temperature -10° ..+70℃, Medium temperature 90℃ Max . |
| Temperature Error |
Additional error when pressure element tmperature
deviates from reference temperature +20° C(+68° F), be ±0.4%/10° C(50° F) rising or falling
|
| Over Pressure Limit |
130% of Full Scale |
| Dial Graduation |
Black graduation on white for single range, Black and red graduation on white for dual ranges |
| Design Material |
Casing and Bezel Ring |
Black painted steel |
| Sensing Element |
Cupreous alloy capsule |
| connection |
Stainless steel |
| Window |
Plain instrement glass |
| Window gasket |
Industrial rubber seal |
| Pointer |
Black painted aluminium |
| Dial Plate |
Aluminium alloy |
| Mounting Code |
L:Bottom entry, W:Bottom with back flange, B:Back entry, F:Back with front flange, Z:Back with bracket |
Why choose us
1: Various style for each products and completely series industry instruments.
2: Large stock for fast shipping .
3: High quality with competitive price .
4: Sample order & small quantity order is acceptable .
5: Customize according to your special request .
Q: Could you offer the free samples ?
A: Yeah, but it depends products, Pls contact us ina@pneuhydr.com or whatsapp 0086 15168536055
Q: What ' s your business scope ?
A: Our business scope is service of exporter automation parts with full container, and sell air cylinder , air source treatment , solenoid valve , air valve, motorize valve , Brass valve, hydraulic valve, hydraulic cylinder, air and oil fitting, pressure gauge etc .
Q: What types of products you can make ?
A: We can make many kinds of stainless steel, brass ,aluminum materials processing .like high pressure Valve / solenoid valve / electric valve / water valve/pneumatic valve/air cylinder/hydraulic valve/hydraulic accumulator products and so on .
Q: Can the product be made with our logo and brand ?
A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization if it is possible .
Q:Can you provide original famous pneumatic and hydraulic,instruments brand goods ?
A: Yes,We can supply like Festo,Smc,Ckd,Burket,Hydac,Rexroth,Siemens,Rosemount,Marsh ,Endress+Hauser etc.
Q: Is there a warranty available?
A: Yes, normally products is one year quality guarantee.
Q: Is the connector in British or Metric system? What is the difference between PT, NPT, and G threads?
A: The G thread is cylindrical and does not seal itself, requiring additional gaskets to prevent leakage. PT and NPT are conical, and the internal and external threads become tighter and tighter when tightened. Sealing is achieved through the deformation of the threads, and sealant or tape is usually used in conjunction to enhance the sealing effect
G-thread is a cylindrical straight pipe used for non sealed connections; PT thread is a conical tube that relies on the deformation and sealing of the thread itself; NPT is also a conical tube with a tooth profile angle of 60 degrees, mainly used in North America
Q: How to convert pressure units: MPa, bar, psi, kg/cm ²?
A: 1MPa=10bar≈145psi≈10kg
Q:What usually causes the burnout of solenoid valve coils?
A:Incorrect voltage and hz, frequent switching, pilot head entering liquid,valve core and spring problem,environment hot,heavy vibration etc.
Q: What should be noted for pneumatic components in high temperature or extremely cold environments?
