Product Details:
Place of Origin: CHINA
Brand Name: NBSANMINSE
Certification: ISO9001
Model Number: SMF18
Payment & Shipping Terms:
Minimum Order Quantity: 10PCS
Price: Negotiation
Packaging Details: Box
Delivery Time: 5-30days
Payment Terms: L/C,T/T
Supply Ability: 10000PCS

NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches

Description
Item Type: Switches Warranty: 12 Months
Min ON: 1.0,2.0,3.0,4.0 Bar Max Off: 5.0,8.0,11.0,16.0 Bar
Differential: 1.0-3.0,1.4-4.0,1.8-4.5 Bar Factory Setting: 2.0-4.0,3.8-5.0,5.6-7.0,8.0-10.0
Highlight:

electronic solenoid valve

,

electric solenoid valve

NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches

ON>OFF is NO , ON<OFF is NC

The images shown are not all the actual item and are for your reference only

NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches 0NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches 1NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches 2NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches 3NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches 4NBSANMINSE SMF18 1/4 3/8 1/2 NPT G Air Compressor And Pump Pressure Switch 3 - Phase Pressure Switches 5

NPT1-2 = NPT 1/2"
NPT1-4 = NPT 1/4"
NPT 3-8 Adapter = NPT 1/4" to 3/8" Adapter

G1-2 = G 1/2"
G1-4 = G 1/4"
G 3-8 Adapter = G1/4" to 3/8" Adapter


The SMF18 pressure switches are used to regulate the tank pressure between two preset values on 3 phase electrically driven air compressors. They are available with an unloader valve, which prevents compressors from starting under load, and it is available with an On-Off knob for manual cut off the compressor.



MODEL
Min ON (Cut-In)(Bar)
Max Off
(Cut-Out) (Bar)
Differential(Bar)
Factory Setting (Bar)
Electrical Rating
Pipe Fittings
Contact Arrangement
Current

SMF18-1
1.0
5.0
1.0-3.0
2.0-4.0
16A
400V
G1/4" or G1/2" Femle
N.C.
SMF18-2
2.0
8.0
1.0-3.0
3.8-5.0
16A
400V
G1/4" or G1/2" Femle
N.C.
SMF18-2
3.0
11.0
1.4-4.0
5.6-7.0
16A
400V
G1/4" or G1/2" Femle
N.C.
SMF18-3
4.0
16.0
1.8-4.5
8.0-10.0
16A
400V
G1/4" or G1/2" Femle
N.C.


Approval: TUV CE, CCC
Optional application: 3-Port connection; Other pipe fitting connection;Conversion: 1 Bar = 14.5 PSI


Why choose us


1: Various style for each products and completely series pneumatic products .

2: Sample order & small quantity order is acceptable .
3: Customize according to your special request .
4: Provide free products information .
5: Large stock for fast shipping .


FAQ


Q: How much is our minimum order quantity ?
A: Our minimun quantity is 1 Piece .


Q: Can the product be made with our logo and brand ?
A: Yes , of course , we can make . we are OEM supplier for years and professional to make . But you need give us the authorization for work.



Q: What is the price of the product ?
A: Our prices are based on the size and type of material , if you can give me the information ,
then we can give you an estimated price is for reference only . We can do any size and any desgin .


Q: what types of products you can make ?
A: We can make many kinds of stainless steel materials and brass,aluminum . Valve / solenoid valve / electric valve / pneumatic valve and air cylinder products and so on .


Q: Could you offer the free samples ?
A: Yeah, we could offer the free samples based on special customer.pre-production sample,production sample.
